The addition of Motor Current Signature Analysis (MCSA) to KCF’s comprehensive machine health platform combines MCSA’s robust motor-electrical diagnostic capabilities with the high-fidelity continuous monitoring, ease of installation, and focus on root cause eradication that are central to KCF’s solutions. Pairing this technology with vibration monitoring results in a comprehensive asset health solution crafted for your most critical electric motors.

KCF offers a suite of products to achieve advanced condition monitoring using MCSA.

These Include:

The IoT Hub: Transmits full-spectrum data to KCF’s machine health platform, SMARTdiagnostics.

Analog Adapters: Connects each of the transformer types to the IoT Hub.

Current Transformers (CTs): Identifies motor faults.

Current Triggering: Enables synchronized sampling on motor startup, enabling the identification of hard to catch phenomena including inrush current.

*Tachometer: Provides precise reading of motor (rotor) turning speed—important for MCSA Analytics Model.

*Potential Transformers (PTs): Enables electrical current signature analysis (ESA). Identifies power supply issues and enables root cause analysis.

Additional Operating Data Uses Unlocked by MCSA in KCF’s Machine Health Platform:

  • Power Consumption
  • Power Factor Duty Cycle (+ total operating hours)
  • Motor Efficiency

When to Use MCSA:

Costs of Downtime Are High: When failure costs a significant sum due to lost production.

Failure Prevention is Essential: When motor replacement cost is significant, or failure results in collateral damage such as product needing to be discarded, or adjacent equipment being damaged.

Regulatory & Fines Risk Reduction: When catastrophic failure results in fines levied against the customer

Advantages of KCF’s MCSA Solution

24/7 Monitoring

Provides continuous online monitoring with 24/7 access to critical data. Effectively covering all blind spots that exist between readings in periodic route-based monitoring.

Triggering

Allows motor behavior during start up to be trended over time, enabling early detection of damaging conditions and motor issues.

Improved Safety

Route-based analysts or
maintenance staff members no longer need to enter dangerous environments to take readings.

Root Cause Analysis

The inclusion of potential
transformers facilitates power supply monitoring. This enables the identification of chronic power supply issues, eliminating the cause of motor faults and suboptimal performance.

Optimize Your Machine Health

Reduce unplanned downtime by getting to the root cause of machine failures. Learn how KCF’s machine health optimization platform will help you achieve peak plant performance. Download the 2022 KCF Guide to learn more about optimizing your machine health.
